Anaconda Multiflex UI-CAP
AnacondaAnaconda is the brand name of our flexible conduits and matching Anaconda fittings. The Anaconda conduits are available in a wide variety of materials, diameters and can be with or without cover. More Multiflex type UI-CAP is a small bore, flexible, fully interlocked, corrosion resistant stainless steel AISI-304 core conduitA conduit is a gateway in which electrical wires or other items can pass through. More with high tensile and compression strength and excellent torque stress characteristics. Developed from the original Anaconda TCA (telephone cable armoring) which was used to protect sensitive wires in public telephone handsets from acts of vandalism, the UI-CAP is typically used in sensitive measuring instruments, optic fibers, surveillance and security systems, robotics and sensor, microphone and telephone cables.
- ConstructionStainless steel (AISI-304) core, fully inter locked. On demand also available in AISI-316
- Temperature-100 °C till + 600 °C
- ColourMetal
- Compression resistance5 (4000N)
- Impact resistance4 (6J)
- Tensile strength4 (1000N)
- Protection classIP 40
| Size | Diameter | Bending radius | Standard carton | Small carton | Reels | Weight | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Inside | Outside | Static | Dynamic | Metre | Article No | Metre | Article No | Metre | Article No | (Kg/m) | |
| (mm) | (mm) | (mm) | (mm) | ||||||||
| 4,5 | 4,5 | 7,5 | 35 | 45 | - | 575.145.0 | - | - | - | - | 0,08 |
| 5 | 5 | 8 | 35 | 45 | - | 575.030.0 | - | - | - | - | 0,09 |
| 5,5 | 5,5 | 8,5 | 40 | 50 | - | 575.040.0 | - | - | - | - | 0,1 |
| 6 | 6 | 9 | 40 | 50 | - | 575.060.0 | - | - | - | - | 0,11 |
| 7 | 7 | 10 | 45 | 55 | - | 575.045.0 | - | - | - | - | 0,12 |
| 8 | 8 | 11 | 45 | 55 | - | 575.840.0 | - | - | - | - | 0,14 |
| 9,5 | 9,5 | 12,5 | 50 | 60 | - | 511.010.0 | - | - | - | - | 0,19 |
