Anaconda Multiflex RWA
AnacondaAnaconda is the brand name of our flexible conduits and matching Anaconda fittings. The Anaconda conduits are available in a wide variety of materials, diameters and can be with or without cover. More Multiflex type RWA is a lightweight aluminum conduitA conduit is a gateway in which electrical wires or other items can pass through. More that is both flexible and corrosion resistant. The conduit is designed for applications in countries that require a UL-1 certification for metal uncovered conduits. The areas of application are various, like p.e. elevators, escalators, lift systems for the disabled, cookers, ovens, burners, household appliances and lamps. RWA can also be used in underground applications to protect cables as it is resistant against corrosion and rodent attacks.
- SpecificsSpecial approvals: Meets the requirements of UL -1 (file # 98045) and CSA (size 3/8” only). Complies with article 348, NEC. Permitted to be used in exposed and concealed locations (article 348.10); enclosed motor leads (article 430.245(B); elevators, escalators, wheelchair lifts (article 620.21). Not suitable for wet locations.
- ConstructionAluminum, continuously inter locked
- Temperature-45 °C till + 260 °C
- ColourMetal
- Compression resistance4 (1250N)
- Impact resistance4 (6J)
- Tensile strength3 (500N)
- Protection classIP 40
| Size | Diameter | Bending radius | Standard carton | Small carton | Reels | Weight | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Inside | Outside | Static | Dynamic | Metre | Article No | Metre | Article No | Metre | Article No | (Kg/m) | |
| (mm) | (mm) | (mm) | (mm) | ||||||||
| 3/8" | 9,8 | 14,9 | 60 | 85 | 30 | 332.012.1 | - | - | - | - | 0,1 |
| 1/2" | 16,1 | 22,6 | 90 | 140 | 30 | 332.016.1 | - | - | - | - | 0,16 |
| 3/4" | 20,9 | 27,3 | 115 | 165 | 30 | 332.020.1 | - | - | - | - | 0,22 |
| 1" | 25,9 | 34 | 145 | 225 | 15 | 332.026.1 | - | - | - | - | 0,38 |
| 1.1/4" | 32,4 | 40,4 | 180 | 270 | 15 | 332.035.1 | - | - | - | - | 0,45 |
| 1.1/2" | 39,1 | 48,3 | 215 | 300 | 7,5 | 332.040.1 | - | - | - | - | 0,57 |
| 2" | 51,8 | 61 | 285 | 390 | 7,5 | 332.050.1 | - | - | - | - | 0,72 |
