Anaconda Sealtite NMFG Blue
Type NMFG is an all plastic, hygienically designed lightweight flexible conduitA conduit is a gateway in which electrical wires or other items can pass through. More that meets the requirements of FDA CFR 21 and NSF / ANSI 51 regulations and EHEDG guidelines. The smooth cover of the conduit is designed to resist microbial accumulation and is easy to clean. The conduit is used to protect cables on processing and packaging machines and equipment in the food and pharmaceutical industries. When used in combination with an Anamet food grade compact fitting an hygienic IP 67 cable protection system with a high pull out strength is achieved.
- ConstructionThick smooth thermoplastic (PVC compound) core reinforced with PVC spiral
- Temperature-35 °C till +60 °C
- ColourBlue
- Compression resistance1 (125N)
- Impact resistance3 (2J)
- Tensile strength4 (1000N)
- Protection classIP 66/67
| Size | Diameter | Bending radius | Standard carton | Small carton | Reels | Weight | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Inside | Outside | Static | Dynamic | Metre | Article No | Metre | Article No | Metre | Article No | (Kg/m) | |
| (mm) | (mm) | (mm) | (mm) | ||||||||
| 3/8" | 12,6 | 17,8 | 70 | 100 | 30 | 359.012.0 | - | - | - | - | 0,12 |
| 1/2" | 16 | 21,1 | 100 | 135 | 30 | 359.016.0 | - | - | - | - | 0,18 |
| 3/4" | 21,1 | 26,4 | 130 | 175 | 30 | 359.020.0 | - | - | - | - | 0,28 |
| 1" | 26,8 | 33,1 | 180 | 220 | 30 | 359.026.0 | - | - | - | - | 0,34 |
| 1.1/4" | 35,4 | 41,8 | 225 | 270 | 15 | 359.035.0 | - | - | - | - | 0,46 |
| 1.1/2" | 40,3 | 47,8 | 255 | 320 | 15 | 359.040.0 | - | - | - | - | 0,6 |
| 2" | 51,6 | 59,9 | 310 | 400 | 15 | 359.050.0 | - | - | - | - | 0,8 |
