Anaconda Sealtite Compact HD Heavy Duty 90° male fitting (NPT)

AnacondaAnaconda is the brand name of our flexible conduits and matching Anaconda fittings. The Anaconda conduits are available in a wide variety of materials, diameters and can be with or without cover. More Heavy Duty compact nickel plated brass fittings are the same as the regular UL/CSA approvedMany of the Anaconda products are listed with the UL and CSA Group. UL is US based but is a global company focused on providing clarity when it comes to safety, compliance, sustainability, transparency, quality and performance. The CSA Group... More compact fittings, however the stamped ferrule is replaced by a machined nickel plated brass ferrule and the nut is additionally marked with “HD”. The machined nickel plated brass ferrules provide a very high pull out strength and assure that the minimum required pull out value of 1556 Newton (350 lbs.) according to the new Heavy Duty standard (CSA C 22.2 No. 18-3) is always guaranteed. These CSA Heavy Duty certified, “HD” marked fittings are suitable for Hazardous locations according to the Canadian electrical Code CEC 2021.

Ask a question

Download PDF

Matching conduits

Specifics
: UL-514B and CSA C 22/2
No. 18.3 HEAVY DUTY (combined UL/CSA file# E 234207).

Suitable for use in hazardousenvironments according to NEC:
- Article 501.10 (B) (2) Class I, Division 2
- Article 502.10 (A) (2) and (B) (2) Class II, Division 1 and 2.
- Article 503.10 (A) (3) and (B) Class III, Division 1 and 2.

CSA approved HEAVY DUTY, suitable for use in hazardous environment according to CEC section 18:
Zone 2, per 18-152-1(i),
Zone 20, per 18-192-3(a),
Zone 21, per 18-202-4(a),
Zone 22, per 18-252-1(i).
Material
Back nut, ferrule and body are nickel plated brass, clamping ring is PA6, flatseal is NBR rubber and lock nut is galvanised steelGalvanised steel is a zinc coated metal that provides customers with better resistance to corrosive environments. More.
Construction
Straight fitting consisting of 6 parts; counter nut, clamping ring, ferrule, body, flat seal and lock nut.
Temperature
- 45 ºC till +105 ºC continious.
Colour
Metal
Protection class
IP 66, IP 67, NEMA 4XThe National Electrical Manufacturers Association (NEMA) defines standards used in North America for various grades of electrical enclosures typically used in industrial applications. More
Thread type
NPT

Thread	Size	Min. Internal Bore	Dimensions in mm						Standard Package	Article Number	Weight
		(mm)	A	B	C	D	E	F			(Kg/100)
NPT 1/2"	1/2"	13,9	25	14	29	30	27	-	10	714.016.2-HD	8,80
NPT 3/4"	3/4"	18,5	27	14	35	33	33	-	5	714.420.2-HD	14,50
NPT 1"	1"	23,8	32	16	45	38	42	-	5	714.426.2-HD	24,00
NPT 1-1/4"	1-1/4"	31,8	36	16	53	39	52	-	2	714.435.2-HD	35,50
NPT 1-1/2"	1-1/2"	36,8	39	18	62	46	60	-	2	714.440.2-HD	51,00
NPT 2"	2"	47,8	44	20	76	53	72	-	2	714.450.2-HD	85,50
