Anaconda Sealtite UVUA Black
AnacondaAnaconda is the brand name of our flexible conduits and matching Anaconda fittings. The Anaconda conduits are available in a wide variety of materials, diameters and can be with or without cover. Leggi SealtiteSealtite is the brand name of the type of conduit that is used to protect wires against different circumstances. Sealtite conduits are often recognized by their think smooth cover. The conduit ensures mechanical protection and is solid, robust and of... Leggi Special type UVUA is a robust conduitA conduit is a gateway in which electrical wires or other items can pass through. Leggi with a hot dipped zinc galvanised steelGalvanised steel is a zinc coated metal that provides customers with better resistance to corrosive environments. Leggi core and a thick, smooth prolonged UV (sunlight) resistant PVC jacket. This type is UL listed and used to protect cables in areas where extreme resistance against UV (sunlight) is required. The UV (sunlight) resistant jacket greatly exceeds UL 360 Sunlight Resistance requirements and independently proven durability, after UV exposure over 3.8 times longer than the UL 360 standard using a Weatherometer.
- CertificazioniUL-360 approved DXHR.E18917, NEC Article 350 and NFPA 79 (2021 Edition) Section 13.5.4 LFMC.
Compliant with NEC Articles:
300.22 (D) Information Technology Equipment.
250.102, 250.118(5) and 250.134(B) Equipment Grounding.
Suitable for hazardous locations per NEC articles
- 501.10 (B) (2) Class I Division 2
- 502.10 (A) (2) and (B) (2) Class II Division 1 and 2
- 503.10 (A) (3) and (B) Class III Division 1 and 2
350 Liquid Tight Flexible Metal Conduit (LFMC)
645.5 (E) (2) Under raised floors - StrutturaHot dipped zinc galvanised steel core, square lock profile with a integral copper grounding wire from size 3/8" till 1-1/4", interlocked profile from size 1-1/2" till 2", thick smooth PVC jacket
- Temperatura di esercizio-40 ºC till +80 ºC, intermittent up to +90 ºC.
- ColoreBlack
- Resistenza compressione4 (1250N)
- Resistenza impatto4 (6J)
- Resistenza trazione4 (1000N)
- Classe di impermeabilitàIP 66/67
| Size | Diameter | Bending radius | Standard carton | Weight | |||
|---|---|---|---|---|---|---|---|
| Inside | Outside | Static | Dynamic | Metre | Article No | (Kg/m) | |
| (mm) | (mm) | (mm) | (mm) | ||||
| 3/8" | 12,6 | 17,8 | 70 | 85 | 30 | 312.712.1 | 0,40 |
| 1/2" | 16,1 | 21,1 | 90 | 110 | 30 | 312.716.1 | 0,45 |
| 3/4" | 21,1 | 26,4 | 115 | 140 | 30 | 312.720.1 | 0,65 |
| 1" | 26,8 | 33,1 | 145 | 170 | 30 | 312.726.1 | 1,05 |
| 1-1/4" | 35,4 | 41,8 | 175 | 215 | 15 | 312.735.1 | 1,20 |
| 1-1/2" | 40,3 | 47,8 | 205 | 250 | 15 | 312.740.1 | 1,50 |
| 2" | 51,6 | 59,9 | 240 | 300 | 15 | 312.750.1 | 2,30 |
